VEHICLE OVERVIEW
The HOWO 30,000 L heavy fuel tanker is the bulk end of the refuelling range: a 30 cbm Q235 carbon-steel tank on an 8x4, 32-tonne chassis with an arc gear oil pump, a complete European bottom-loading kit and dispenser options, for long-haul fuel logistics and large-site refuelling.
Typical applications: Long-haul bulk fuel transport and large-site refuelling.
KEY FEATURES
What this configuration offers
Multi-compartment option
Single standard, multiple compartments customizable.
Itemised bottom loading kit
Valve, vapour recovery set, pneumatic switches, overfill probe and socket all named.
TECHNICAL DETAILS
Specifications by system
Values shown are for the listed configuration. Confirm the final chassis, payload and equipment before ordering.
Chassis and dimensions
- Chassis
- HOWO ZZ1326N466GF1K, 8x4, wheelbase 1,800+3,775+1,400 mm
- Engine brand
- HOWO / Weichai (options listed); 351-450 hp bucket
- Other equipment
- European-standard manhole cover, bottom loading/emergency valve, toolbox, two hoses, two fire extinguishers (listed)
- Overall dimensions
- 11,860 x 2,550 x 3,600 mm; front/rear overhang 1,450/2,635 mm
- Tyres
- 295/80R22.5
Body and tank
- Media
- Diesel, gasoline, engine oil (listed)
- Tank
- 30,000 L Q235 carbon steel, single compartment (multi customizable)
- Wall thickness
- 4-6 mm (customizable, listed)
Working equipment
- Bottom loading
- Complete kit with overfill prevention probe and vapour recovery (listed)
- Bottom loading kit
- Bottom loading/unloading valve, vapour recovery valve and adapter, pneumatic combination switches, overfill prevention probe and socket (listed)
- Pump
- Arc gear oil pump, in and out (listed)
Operating performance
- GVW / curb weight
- 32,000 kg / 13,470 kg
- Max speed
- 80 km/h (listed)
- Payload
- 18,335 / 18,400 kg (two values listed)
Safety
- ABS
- Yes (listed)
- Overfill prevention
- Probe and socket (listed)
Equipment and options
Listed equipment
- Arc gear oil pump
- Bottom loading kit
- Vapour recovery valve and adapter
- Overfill prevention probe
- European manhole cover
- Two fire extinguishers
What to confirm for your quote
- Delivery
- Quantity, destination country and port, steering side.
- Operating brief
- Fuels and compartment needs, litres per run, delivery radius, loading terminal type
Final quotation checks
- Commercial scope
- Confirm chassis availability, emission option, delivery basis, inspection and spare-parts list in the quotation.
- Technical scope
- Confirm the exact chassis, body or tank build, working equipment and rated loads on the agreed configuration.
Frequently asked questions
Can the tank have multiple compartments?
It is listed as single-compartment with multiple compartments customizable - useful for carrying different fuels in one run.
How much can it carry?
GVW is 32,000 kg with a 13,470 kg curb weight; payload is listed at 18,335 / 18,400 kg. Fuel density determines how much of the 30,000 L you can legally load.
What equipment comes with the tank?
The listing itemises an arc gear oil pump, a complete bottom loading kit (valve, vapour recovery set, pneumatic switches, overfill probe and socket), a European-standard manhole cover, emergency valve, toolbox, two hoses and two fire extinguishers.
What is it for?
Long-haul fuel logistics and large-site refuelling where a 30 cbm load per trip matters.
