VEHICLE OVERVIEW
The HOWO 25 t combined sewer cleaner pairs a 10.36 cbm sludge tank with an 8.2 cbm water tank on a 6x4 chassis. Listed Weichai and Sinotruk MC-series engine options span 270–403 hp for large sewer networks and industrial cleaning duties.
Typical applications: Large sewer networks, industrial sludge ponds and critical pipeline maintenance.
KEY FEATURES
What this configuration offers
18.56 cbm dual tanks
A 10.36 cbm sludge tank and an 8.2 cbm water tank in one combined cleaning system.
10-plus engine options
Weichai and Sinotruk MC series from 270 to 403 hp.
TECHNICAL DETAILS
Specifications by system
Values shown are for the listed configuration. Confirm the final chassis, payload and equipment before ordering.
Chassis and dimensions
- Chassis
- Sinotruk HOWO 3-axle 6x4, U-profile ladder frame, 7 t front / 18 t dual rear axles
- Dimensions
- 9,900 / 10,200 x 2,550 x 3,750 / 3,950 mm (variants)
- Electrics
- 24 V, satellite positioning with real-time tracking, ETC ready (listed)
- Engine options
- Weichai WP7H270E62 (270 hp) to MC11.40-61 (403 hp), 10-plus options (listed)
- GVW
- 25,000 kg (listed)
- Transmission
- Manual with PTO (listed)
- Tyres
- 12.00R20 16PR or 315/80R22.5, 10 tyres
- Wheelbase
- 4,300+1,350 or 4,600+1,350 mm (options)
Body and tank
- Sludge tank
- 10.36 cbm high-strength steel, anti-corrosion
- Water tank
- 8.2 cbm
Working equipment
- Discharge
- Rear dump with hydraulic lifting and top-opening rear door (listed)
- Pumps
- Vacuum pump plus high-pressure water pump (listed)
Safety
- ABS
- WABCO 4460046300 (listed)
- Brakes
- Dual-circuit air, spring parking, exhaust brake
- Braking
- Dual-circuit air, spring parking, engine exhaust brake; WABCO ABS (listed)
What to confirm for your quote
- Delivery
- Quantity, destination country and port, steering side.
- Operating brief
- Network size, sludge volumes, pipe diameters, water refill access
Final quotation checks
- Commercial scope
- Confirm chassis availability, emission option, delivery basis, inspection and spare-parts list in the quotation.
- Technical scope
- Confirm the exact chassis, body or tank build, working equipment and rated loads on the agreed configuration.
Frequently asked questions
How does it discharge?
The tank lifts hydraulically with a top-opening rear door for complete, rapid dumping at disposal sites.
What capacity does it carry?
The listed configuration has a 10.36 cbm sludge tank and an 8.2 cbm water tank, for 18.56 cbm combined tank volume. Confirm the final usable capacities before ordering.
What engine choices are there?
A 10-plus option menu from Weichai and Sinotruk: WP7H270E62 (270 hp), MC07.29-61 (289 hp), MC07H.35-61 (345 hp), WP8.350E61 (349 hp), WP10H400E62 (399 hp), MC11.40-61 (403 hp).
What safety equipment is listed?
WABCO ABS, dual-circuit air braking with spring parking brake and engine exhaust brake.
