VEHICLE OVERVIEW
The gas cylinder delivery van is a light 4x2 CLW built for distributors moving bottled gas to homes, restaurants and workshops: an aluminium-plate closed body in several lengths, payload variants of 1,800-2,023 kg and a 4,495 kg GVW that keeps it in the light commercial class for urban routes.
Typical applications: Bottled gas cylinder delivery to homes, restaurants and workshops.
KEY FEATURES
What this configuration offers
Five body lengths
3,400-3,750 mm body options let buyers match cylinder loads to routes.
4,495 kg listed GVW
Check vehicle and bottled-gas transport licensing for the destination route.
TECHNICAL DETAILS
Specifications by system
Values shown are for the listed configuration. Confirm the final chassis, payload and equipment before ordering.
Chassis and dimensions
- Axle loads
- 1,617/2,878 kg or 1,800/2,695 kg
- Chassis
- CLW CL5042TQP6BXW, 4x2, wheelbase 2,800 / 2,850 / 3,360 mm options
- Engine
- Q23-115E60 diesel, below 150 hp (listed)
- Overall length
- 5,200-5,540 mm depending on configuration
- Transmission
- Automatic (basic field); confirm final driveline
- Tyres
- 6.50R16LT 10PR or 195/75R16 10PR
Body and tank
- Body
- Closed aluminium-plate van body, lengths 3,400-3,750 mm, widths 1,850/1,940 mm, side heights 400-550 mm (options listed)
- Body sizes
- L 3,400-3,750 mm / W 1,850-1,940 mm / H 400-550 mm options
- Body type
- Closed aluminium-plate van for gas cylinders
Operating performance
- Fuel consumption
- 11.12-11.40 L/100 km (listed)
- GVW / curb weight
- 4,495 kg / 2,342-2,565 kg (configuration variants)
- Max speed
- 80 km/h (listed)
- Payload
- 1,800 / 1,865 / 2,023 kg (three variants listed)
Safety
- Rear guard
- Q235B underrun guard, 120 mm section, 435 mm ground clearance (listed)
Equipment and options
Listed equipment
- Aluminium-plate body
- Q235B rear underrun guard
What to confirm for your quote
- Delivery
- Quantity, destination country and port, steering side.
- Operating brief
- Daily cylinders delivered, body size needed, route type
Final quotation checks
- Commercial scope
- Confirm chassis availability, emission option, delivery basis, inspection and spare-parts list in the quotation.
- Technical scope
- Confirm the exact chassis, body or tank build, working equipment and rated loads on the agreed configuration.
Frequently asked questions
How much can it carry?
Payload variants of 1,800, 1,865 and 2,023 kg are listed against a 4,495 kg GVW; confirm your configuration in the quotation.
What body sizes are available?
Body lengths from 3,400 to 3,750 mm, widths of 1,850 or 1,940 mm and side heights of 400-550 mm are offered.
What is it built for?
Delivering bottled gas cylinders as dangerous goods to homes, restaurants and workshops on urban routes, in a closed ventilated aluminium-plate body.
What licence does it need?
Listed GVW is 4,495 kg. Confirm local commercial vehicle and bottled-gas transport licensing before ordering.
