VEHICLE OVERVIEW
The compact electric hook arm truck brings container waste collection into emission-regulated city zones: a 2,500-litre container on a light 4x2 EV chassis with CATL 46 kWh LFP battery, 220 km range at full load, 60 kW peak motor and an 820 kg payload.
Typical applications: Light container waste collection in campuses, estates and old towns.
KEY FEATURES
What this configuration offers
4.9 m footprint
Works lanes and gates that block sanitation lorries.
Zero-emission collection
CATL 46 kWh LFP battery with 220 km full-load range.
TECHNICAL DETAILS
Specifications by system
Values shown are for the listed configuration. Confirm the final chassis, payload and equipment before ordering.
Chassis and dimensions
- Chassis
- 4x2 EV chassis (SC1032DBADBEV listed), 3,200 mm wheelbase, 175R14LT tyres
- Overall dimensions
- 4,860 or 4,660 x 1,665 or 1,620 x 2,050 or 2,020 mm (variants)
Body and tank
- Body hoist motor
- 5.5 kW rated (listed)
- Container
- 2,500 L square body (listed)
Working equipment
- Battery
- CATL LFP 46 kWh, 220 km range, 1.15 h fast charge
- Hook arm
- Hydraulic, with 5.5 kW hoist motor (listed)
- Hook system
- Hydraulic hook arm for container loading and unloading (listed)
- Motor
- Permanent-magnet synchronous, 30 kW rated / 60 kW peak, Suzhou Inovance (listed)
- Range / charging
- 220 km at full load; about 1.15 h at recommended 120 kW charger (listed)
Operating performance
- GVW / curb weight / payload
- 2,695 kg / 1,745 kg / 820 kg
- Max speed
- 100 km/h (listed); ABS (WX80 model listed)
Safety
- ABS
- WX80 (listed)
What to confirm for your quote
- Delivery
- Quantity, destination country and port, steering side.
- Operating brief
- Container positions, daily rounds, charging availability
Final quotation checks
- Commercial scope
- Confirm chassis availability, emission option, delivery basis, inspection and spare-parts list in the quotation.
- Technical scope
- Confirm the exact chassis, body or tank build, working equipment and rated loads on the agreed configuration.
Frequently asked questions
How far can it go per charge?
220 km at full load is listed, with about 1.15-hour fast charging at the recommended 120 kW charger.
What can it carry?
820 kg payload on a 2,695 kg GVW - light containers in campuses, estates and old towns.
What container does it handle?
A 2,500-litre square container, loaded and unloaded by the hydraulic hook arm.
Why electric?
Zero-emission operation with low noise for regulated city zones; running cost per km is lower than diesel (claimed, verify for your grid).
